ELO 1502L Touch Monitor, 15,6″, Full HD 1920x1080p














ELO 1502L Touch Monitor, 15,6″, Full HD 1920x1080p
4.635,00kr. Ekskl. moms
15.6″ 1920 x 1080 TFT LCD (LED), 180 nits, 30 ms, Anti-glare, 16:9, PCAP, USB, VGA, HDMI
Stock visibility På lager – 2-5 dages levering
- Beskrivelse
- Yderligere information
- Dokumenter
Beskrivelse
Elo Touch Solutions E155645. Display diagonal: 39.6 cm (15.6″), Display technology: LED, Display resolution: 1920 x 1080 pixels, HD type: Full HD, Touchscreen. Product colour: Black
Elo’s 1502L
Touchscreen Monitor
The Elo 1502L Touchscreen Monitor is designed with the same seamless style that spans across the entire line up of 02-Series Monitors. With a compact form factor and clean design for easy integration, the 1502L offers the flexibility to install as a traditional POS terminal or a customer facing point of interaction – making it well-suited for point-of-sale, self-service, signage and hospitality applications. And with a variety of peripherals, the monitor can be transformed to meet the demands of almost any blueprint.
Single Cable Connection
The 1502L provides a USB Type-C interface that provides touch, video and power. By reducing the number of cables required for any set up from 3 to 1, installation and servicing is a breeze. In case your PC isn’t equipped with USB Type-C yet, you can still use traditional HDMI or VGA to connect to your PC.
One for You.
One for Your Customers.
The 02-Series offers dual functionality. Use it as a traditional POS terminal or customer facing display – or BOTH! Start increasing brand loyalty and customer satisfaction by offering your customers a point of interaction to review transactions, participate in loyalty programs or see the latest promotion.
Well-Suited for…
Not all businesses have the same needs. Whether you need a touchscreen at the point of sale to process a transaction or in a restaurant to enable self-service for guests to view your menu and submit their order, the line of 02-Series monitors can support the installation needs with ease while maintaining a modern, sleek aesthetic.
Elo Edge Connect™ Lets You do More!
Built with versatility in mind, the Elo Edge Connect system offers a wide assortment of peripheral options. Whether for endless aisle, self-order or collaboration applications, you can seamlessly attach any combination of up to four peripherals to the edge of the touchscreen creating a bespoke solution. And, you can add or move them later as your needs change!
Mount with Flexibility
Customers demand a seamless shopping experience from their first step into the store through check-out. From the stands that come with the monitors to pole mounts, shelf mounts, wall mounts and 3rd party kiosk enclosures, the touchscreens can be integrated with ease.
Yderligere information
Product colour | |
---|---|
Skærmstørrelse | |
Vertical scan range | 50 – 75 Hz |
Display resolution | |
Native aspect ratio | 16:9 |
Horizontal scan range | 31.5 – 82 kHz |
Display diagonal | |
Response time | 30 ms |
Supported graphics resolutions | 640 x 400, 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1280 x 960, 1360 x 768 (WXGA), 1366 x 768, 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+) |
HD type | |
Viewing angle, vertical | 160° |
Contrast ratio (typical) | 700:1 |
Viewing angle, horizontal | 160° |
RMS rated power | 2 W |
Built-in speaker(s) | Yes |
HDMI ports quantity | |
Power consumption (typical) | 9.5 W |
Power consumption (standby) | 1.87 W |
AC input frequency | 50 – 60 Hz |
AC input voltage | 100 – 240 V |
Storage relative humidity (H-H) | 10 – 95% |
Operating temperature (T-T) | 0 – 40 °C |
Operating relative humidity (H-H) | 20 – 80% |
Storage temperature (T-T) | -20 – 60 °C |
Package width | 204 mm |
Cables included | AC, HDMI, USB Type-A to USB Type-C |
Package depth | 451 mm |
Package weight | 5.01 kg |
Package height | 344 mm |
On Screen Display (OSD) | Yes |
Panel mounting interface | 75 x 100 mm |
Power consumption (off) | 0.2 W |
Quick start guide | Yes |
Depth (with stand) | 199.1 mm |
Viewable size, horizontal | 34.4 cm |
Width (with stand) | 284.6 mm |
DC-in jack | Yes |
Display technology | |
Viewable size, vertical | 19.4 cm |
Height (with stand) | 387 mm |
Touchscreen | Yes |
Package type | Box |
VESA mounting | Yes |
Panel type | TFT |
Anti-glare screen | Yes |
Display number of colours | 262144 colours |
International Protection (IP) code | IPX1 |
Weight (with stand) | 3.05 kg |
Energy efficiency scale | A to G |
Harmonized System (HS) code | 85285210 |
Energy efficiency class (SDR) | E |
Energy consumption (SDR) per 1000 hours | 12 kWh |
Screen shape | Flat |
