Elo 1593L, 15.6″, LCD Touchscreen, 1366×768 pixels
Elo 1593L, 15.6″, LCD Touchscreen, 1366×768 pixels
$705.66 Excl. VAT
ET1593L TouchPro PCAP, 15.6″, 10 ms, 270 cd/m², 1366 x 768, TFT-LCD, 500 : 1, 16 : 9, HDMI, VGA, Black
Stock visibility Not in stock
- Description
- Additional information
- Dokumenter
Description
Elo Touch Solutions 1593L. Display diagonal: 39.6 cm (15.6″), Display technology: LED, Display resolution: 1366 x 768 pixels, Display brightness: 270 cd/m², Touchscreen. Product colour: Black
The Elo 1593L 15-inch open-frame LCD touch display features a slim design and narrow outside dimensions due to the state-of-the-art, energy-saving LED backlight, using less electricity to operate and generating less heat. This compact touch display is designed for touch with proven Elo expertise and reliability built in. The 1593L provides stable, drift-free operation with outstanding image clarity and light transmission—for accurate touch responses and vivid images. Instantly grabbing and holding users’ attention, the 15.6-inch open frame is perfect for kiosks, casino and amusement, retail self-service, and industrial automation environments.
Easily integrated.
The touchscreen is sealed against dirt, dust and liquids, which simplifies integration into the final enclosure. Projected capacitive (PCAP) units can be sealed into a solution and obtain an IP65 rating on the front side of the unit. With the design and tooling being controlled by Elo, long-lasting product availability can be expected as well as backwards compatibility where we can make it possible to help minimize additional enclosure costs.
Touch ready.
Available with a choice of industry leading touch technologies, in single- or multi-touch technology, including IntelliTouch® single-touch surface acoustic wave (SAW) touchscreen technology, and our latest zero-bezel TouchPro™ PCAP two-glass solution (2GS) technology that delivers both a 10-touch tablet-like experience along with two-touch thru-glass functionality—both modes support single or dual latex gloves as well as cloth gloves.
Commercial-grade.
The Elo open frame touchscreen display delivers the quality and reliability Elo is known for, and is backed by our three-year standard warranty. We design, build and are responsible for the complete solution, with touch integrated from the start. Using our touchscreens combined with our software and drivers, everything is designed to work together and is tested as part of our life-testing processes. All our products go through rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF.
Other features.
– Projected capacitive (PCAP) two glass solution (2GS) offers pristine optical clarity and touch durability that passes UL-60950 & IK-07 impact testing
– 10-touch TouchPro projected capacitive (PCAP) with two-touch thru-glass capabilities
– Display Port and VGA video interfaces
Additional information
| Product colour | |
|---|---|
| Display brightness | |
| Display resolution | |
| Display diagonal | |
| Response time | 10 ms |
| Supported graphics resolutions | 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1366 x 768 |
| Viewing angle, vertical | 160° |
| Contrast ratio (typical) | 500:1 |
| Viewing angle, horizontal | 160° |
| HDMI ports quantity | |
| Power consumption (typical) | 13.6 W |
| Power consumption (standby) | 1.5 W |
| Storage relative humidity (H-H) | 10 – 95% |
| Operating temperature (T-T) | 0 – 40 °C |
| Operating relative humidity (H-H) | 20 – 80% |
| Storage temperature (T-T) | -20 – 60 °C |
| Package width | 470 mm |
| Cables included | HDMI, VGA |
| Package depth | 175 mm |
| Package weight | 4.62 kg |
| Package height | 331 mm |
| Number of OSD languages | 8 |
| On Screen Display (OSD) languages | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese |
| Panel mounting interface | 75 x 75 mm |
| Power consumption (off) | 0.5 W |
| Backlight type | LED |
| Digital vertical frequency | 50 – 75 Hz |
| DisplayPorts quantity | 1 |
| Built-in microphone | No |
| Aspect ratio | 16:9 |
| Power consumption (PowerSave) | 0.7 W |
| Display technology | |
| Mean time between failures (MTBF) | 50000 h |
| Built-in camera | No |
| Digital horizontal frequency | 30 – 82 kHz |
| Touchscreen | Yes |
| Depth (without stand) | 43.4 mm |
| Display viewable area (HxV) | 344.232 x 193.536 mm |
| Weight (without stand) | 3.02 kg |
| Height (without stand) | 242 mm |
| VESA mounting | Yes |
| Power supply type | DC |
| Display number of colours | 16.78 million colours |
| Harmonized System (HS) code | 85285210 |
| Touchscreen technology | Projected capacitive system |
| Wall mountable | Yes |
| Screen shape | Flat |
