Elo 2794L 27-inch wide FHD LCD WVA (LED Backlight), Open Frame
HIGHLIGHTS
- Black
- 68.6 cm (27") 1920 x 1080 pixels LCD 270 cd/m²
- Touchscreen 12 ms
Elo 2794L 27-inch wide FHD LCD WVA (LED Backlight), Open Frame
8 955,83 kr Ekskl. moms.
27″, 1920×1080 50, 60Hz, 270 nits, 10-touch
- Beskrivning
- Ytterligare information
- Dokument
Beskrivning
Elo Touch Solutions 2794L. Display diagonal: 68.6 cm (27″), Display technology: LCD, Display resolution: 1920 x 1080 pixels, Display brightness: 270 cd/m², HD type: Full HD, Touchscreen. Product colour: Black
Elo 2794L Open Frame Touchscreen Display
The Elo 2794L 27-inch open frame touchscreen display delivers an industrial-grade solution that is cost-effective for OEMs and systems integrators requiring a reliable product for their customers. Designed with reliability from the start, Elo’s open frames deliver outstanding image clarity and light transmission with stable, drift-free operation for accurate touch responses. The 90-Series product line is available in a wide range of sizes, touch technologies and brightness, offering the versatility needed for commercial kiosk applications from self-service and gaming to industrial automation and healthcare.
Enabling Partners to Build Smarter Kiosks
With EloView® and the Backpack, managing kiosks is EASY! The Elo Backpack is an Android powered compute engine capable of transforming Elo touchscreens into an affordable, scalable, single-architecture media platform. With its simplified content-delivery and remote-management capabilities via the EloView portal, the Backpack provides a low-power, solid-state, fan-less computing solution with the capability to simplify deployments and remotely manage kiosks out-of-the-box.
Flexibility for Your Install
Our commercial-grade open frames can be mounted in landscape, portrait, and face-up orientations providing optimal flexibility for mounting in any table, kiosk, or cabinet design. Whether viewing directly, at an angle, or from a distance, our open frames offer what you need while maintaining optimal clarity and the viewing experience you want to deliver.
Touch Thru Glass. Enabled with PCAP
Our TouchPro® PCAP technology supports touch thru functionality for installations that require a front layer of glass with thickness’s up to 6mm or solutions that require specific IP ratings. Whether you need a flush-mounted display or one that is fully-encased behind a cover glass, our robust PCAP Open Frames are purpose-built for durability in various applications and environments: from self-service kiosks to highly used gaming cabinets to harsh industrial machines.
Built for Commercial Use
We pride ourselves on being one of the best manufacturers in the market – We design and build the complete solution, with touch integrated from the start. Our robust touchscreen solutions offer flexibility for diverse environments and have undergone rigorous testing to ensure the longest life possible for our product – maximizing your ROI.
3 Years
Ytterligare information
| Display diagonal | 68.6 cm (27") |
|---|---|
| Display technology | LCD |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 270 cd/m² |
| Touchscreen | Yes |
| LED backlight | Yes |
| Touchscreen technology | Projected capacitive system |
| Response time | 12 ms |
| Contrast ratio (typical) | 3000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.78 million colours |
| HDMI ports quantity | 1 |
| Product colour | Black |
| VESA mounting | Yes |
| Screen shape | Flat |
| On Screen Display (OSD) languages | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese |
| Power consumption (typical) | 21 W |
| Power consumption (off) | 0.5 W |
| Package width | 782 mm |
| Package depth | 200 mm |
| Package height | 530 mm |
| Package weight | 10.2 kg |
| Cables included | HDMI, USB, VGA |
| Operating temperature (T-T) | 0 – 40 °C |
| Operating relative humidity (H-H) | 20 – 80% |
| Storage temperature (T-T) | -20 – 60 °C |
| Storage relative humidity (H-H) | 10 – 95% |
| Harmonized System (HS) code | 85285210 |
| Maximum refresh rate | 65 Hz |
| Display viewable area (HxV) | 597.6 x 336.15 mm |
| Weight (without stand) | 7.3 kg |
| Power supply type | DC |
| Built-in camera | No |
| HD type | Full HD |
| Panel type | TFT |
| Number of simultaneous touchpoints | 10 |
| Native aspect ratio | 16:9 |
| Mean time between failures (MTBF) | 50000 h |
| Wall mountable | Yes |
| Digital horizontal frequency | 30 – 82 kHz |
| Digital vertical frequency | 50 – 75 Hz |
| Height (without stand) | 40.6 mm |
| Depth (without stand) | 388.4 mm |
| HDMI version | 1.3a |
| DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| On Screen Display (OSD) | Yes |
| Power consumption (max) | 27 W |
| Energy efficiency class (SDR) | G |
| Energy consumption (SDR) per 1000 hours | 30 kWh |
| Energy efficiency scale | A to G |
| Backlight type | LED |
| Viewable size, horizontal | 59.8 cm |
| Viewable size, vertical | 33.6 cm |
| DisplayPort version | 1.1a |
| Compliance certificates | RoHS |
| Bezel width | 0 mm |
| Connection to PC | Yes |
