Elo E-series 2 POS, All-In-One, 15”, Windows 10, Intel Celeron






HIGHLIGHTS
- All-in-One TFT 39.6 cm (15.6") Built-in cash drawer Black
- Touchscreen
- Intel® Celeron® 2 GHz 4 MB
- DDR4-SDRAM 4 GB
- SSD 128 GB
- Built-in speaker(s)
- Ethernet LAN Powered USB
- VESA mounting Panel mounting interface: 75 x 100 mm
- 180 W
Elo E-series 2 POS, All-In-One, 15”, Windows 10, Intel Celeron
7.195,00kr. Ekskl. moms
15.6” 1366 x 768 TFT LCD (LED), 60Hz, Win 10, Intel Celeron Processor J4125 (4M Cache, up to 2.7 GHz), 4GB 2666MHz DDR4 SO-DIMM, 128GB M.2 SATA SSD, 1 x LAN RJ45, 2 x 2W, 180W
- Beskrivelse
- Yderligere information
Beskrivelse
Elo Touch Solutions E136131. Display diagonal: 39.6 cm (15.6″), Display resolution: 1366 x 768 pixels, Display type: TFT. Processor family: Intel® Celeron®, Processor model: J4125, Processor frequency: 2 GHz. Internal memory: 4 GB, Internal memory type: DDR4-SDRAM, Maximum internal memory: 8 GB. Total storage capacity: 128 GB, Storage media: SSD, SSD capacity: 128 GB. Graphics card manufacturer: Intel, Graphics card: UHD Graphics 600
E-Series 2 POS system.
Purpose-built for point of sale, the E-Series 2 offers a 15.6-inch touchscreen display, Intel’s 8th generation Celeron processor and an integrated expansion hub to connect the peripherals you need.
Expand with Elo Edge Connect.
Seamlessly attach any combination of up to four peripherals to the edge of the touchscreen creating a bespoke solution. And, you can add or move them later as your needs change!
Add a customer-facing display with ease.
The E-Series 2 includes USB-C connectivity, allowing you to easily connect a customer-facing display – providing touch, data and power with just one cable.
Connect all of your POS accessories.
Integrated into the base of the stand, the expansion hub allows you to connect all of the POS peripheral support you need. From cash drawers and printers to barcode scanners and payment devices — there is connectivity to cover it all.
Windows or Linux. You choose.
The E-Series 2 utilizes the reliability-tested performance and security of Intel’s 8th Generation Celeron processor, integrated Trusted Platform Modules and the Windows 10 operating system. For added flexibility, the E-Series 2 offers models with no OS – all pretested with Linux SuSE, Ubuntu and Red Hat operating systems.
A POS system you can count on.
Rigorously tested and backed by a three-year warranty. With splash-proof housing and a rugged retail-hardened design, the E-Series 2 can withstand the adverse conditions associated with most commercial environments.
3 year
Yderligere information
Display diagonal | 39.6 cm (15.6") |
---|---|
Display resolution | 1366 x 768 pixels |
Touchscreen | Yes |
Display type | TFT |
Display brightness | 187 cd/m² |
Contrast ratio (typical) | 400:1 |
Viewing angle, horizontal | 45° |
Viewing angle, vertical | 50° |
Response time | 10 ms |
Effective viewing area | 344.2 x 193.5 mm |
Aspect ratio | 16:9 |
Display number of colours | 262144 colours |
Processor family | Intel® Celeron® |
Processor model | J4125 |
Processor frequency | 2 GHz |
Processor cores | 4 |
Processor cache | 4 MB |
Processor front side bus | 2.7 MHz |
Internal memory | 4 GB |
Internal memory type | DDR4-SDRAM |
Maximum internal memory | 8 GB |
Number of memory slots | 2 |
Memory slots type | SO-DIMM |
Memory clock speed | 2666 MHz |
Total storage capacity | 128 GB |
Storage media | SSD |
Number of storage drives supported | 1 |
SSD capacity | 128 GB |
SSD interface | SATA |
SSD form factor | M.2 |
Graphics card manufacturer | Intel |
Graphics card | UHD Graphics 600 |
Certification | UL/cUL, FCC, TUV, CE, CB, NOM, S-Mark, UKCA |
Built-in speaker(s) | Yes |
Number of speakers | 2 |
Ethernet LAN | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ethernet LAN (RJ-45) ports | 1 |
USB 2.0 ports quantity | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
Powered USB | Yes |
Serial ports quantity | 1 |
Chassis type | All-in-One |
Product colour | Black |
Built-in cash drawer | Yes |
Trusted Platform Module (TPM) | Yes |
Trusted Platform Module (TPM) version | 2.0 |
Operating system installed | Windows 10 |
AC input voltage | 100 – 240 V |
AC input frequency | 50 – 60 Hz |
AC adapter output voltage | 24 V |
Power supply | 180 W |
Power consumption (typical) | 24 W |
Operating relative humidity (H-H) | 20 – 80% |
Operating temperature (T-T) | 0 – 35 °C |
Storage temperature (T-T) | -20 – 60 °C |
Storage relative humidity (H-H) | 5 – 95% |
VESA mounting | Yes |
Panel mounting interface | 75 x 100 mm |
Mean time between failures (MTBF) | 50000 h |
Width | 386.2 mm |
Depth | 369.3 mm |
Height | 221.2 mm |
Weight | 4.7 kg |
Package width | 462 mm |
Package depth | 299 mm |
Package height | 470 mm |
Package weight | 6.9 kg |
Cable lock slot | Yes |
Cable lock slot type | Kensington |
