Bixolon XM7-20, USB-C, RS232, BT (iOS), 8 dots/mm (203 dpi), display, ZPLII, CPCL
Bixolon XM7-20, USB-C, RS232, BT (iOS), 8 dots/mm (203 dpi), display, ZPLII, CPCL
Direct thermal, 203 dpi, 152 mm/s, 128 MB RAM, 256 MB FlashROM, USB-C, RS232, BT (iOS), 8 dots/mm, display, ZPLII, CPCL
3.768,00kr.
- Description
- Additional information
Description
Bixolon XM7-20. Print technology: Direct thermal, Type: Mobile printer, Maximum resolution: 203 x 203 DPI. Maximum roll diameter: 5.7 cm, Supported paper width: 25 – 58 mm, Maximum printing width: 4.8 cm. Connectivity technology: Wired & Wireless, USB connector: USB Type-C, Serial interface type: RS-232. Internal memory: 128 MB, Page description languages: CPCL-native, ZPL II, Storage media: Flash. Product colour: Black, Display: LCD, Display resolution: 240 x 320 pixels
Compact yet Resilient
The XM7-20 is a compact, yet rugged 2-inch (58mm) premium level Auto-ID Mobile Liner and Linerless Label printer featuring an intuitive design and value add software support. A premium level printer, capable of speeds up to 6ips at 300dpi print resolution, it provides a drop protection of 2.1 metres and an IP54 protection rating. Through a smart battery with universal USB Type-C Power delivery charging, this mobile label printer provides a wealth of battery health information through BIXOLON’s web-based printer profile management software XPM™, guaranteeing consistent performance throughout prolonged operations, making it ideal for Logistics, Manufacturing, Retail and Healthcare printing applications.
A high connective device, the XM7-20 presents USB 2-0 and Serial interfaces as standard, with optional Bluetooth V5.0 Classic (MFi Certification) and WLAN 802.11a/b/g/n wireless technology which can be connected simultaneously. Supporting easy Bluetooth pairing via NFC allows compatibility with major operations including Android™, iOS™ and Windows™. The printer also boasts compatibility with market leading command languages such as SLCS, BPL-Z™, BPL-C™ and BXL/POS to allow for seamless integration with customers’ existing systems.
Boasting a 128 MB SRAM, 256 MB Flash memory as standard and optional 256 MB SDRAM, 512 MB Flash memory enabling the storage of fonts and graphics, alongside firmware upgrades and tools. The XM7-20 can print directly from SAP® Smart Forms and is compatible with a range of label editing applications including BIXOLON’s Label Artist™, Label Artist Mobile™ for iOS™ & Android™, alongside the industry leading Bartender® software.
Additional information
| Print technology | Direct thermal |
|---|---|
| Type | Mobile printer |
| Print speed | 152 mm/sec |
| Supported paper width | 25 – 58 mm |
| Connectivity technology | Wired & Wireless |
| USB port | Yes |
| Ethernet LAN | No |
| Product colour | Black |
| Width | 92.9 mm |
| Depth | 168.2 mm |
| Height | 69.2 mm |
| Weight | 600 g |
| Harmonized System (HS) code | 84433210 |
| Maximum resolution | 6 ips |
| Maximum printing width | 4.8 cm |
| Serial interface | Yes |
| Serial interface type | RS-232 |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Storage media | Flash |
| Flash memory | 256 MB |
| Built-in display | Yes |
| Colour display | No |
| Power source type | Battery |
| Operating temperature (T-T) | -15 – 50 °C |
| Storage temperature (T-T) | -30 – 70 °C |
| Operating relative humidity (H-H) | 10 – 80% |
| Windows operating systems supported | Yes |
| Sustainability certificates | ENERGY STAR |
| Wi-Fi | Yes |
| Mac compatibility | Yes |
| Mobile operating systems supported | Android, iOS |
| USB connector | USB Type-C |
| Battery capacity | 2850 mAh |
| Maximum roll diameter | 5.7 cm |
| Character sets | 16 BPL-Z, SLCS |
| Display resolution | 240 x 320 pixels |
| Media thickness | 0.07 ± 0.19 mm |
| Internal memory | 128 MB |
| Page description languages | CPCL-native, ZPL II |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery voltage | 7.2 V |
| International Protection (IP) code | IP54 |
| Printable dot numbers | 8 dot |
| Drivers included | Yes |
| Display | LCD |
