Datalogic Gryphon I GBT4500, Imager, 2D, BT, Digimarc








HIGHLIGHTS
- 1 MP optics for superior scanning and Depth of Field
- Datalogic distinctive technology with highly visible white-illumination and 4-Dot aimer
- with center cross for targeted scanning
- Datalogic’s ‘Green Spot’ technology, exclusive 3GL™ (3 Green Lights) and Vibration for
- superior good-read feedback
- Motionix™ motion-sensing technology for seamless reading mode transitions
- Image capture and document scanning capabilities
- Omnidirectional reading of 1D, 2D and postal codes plus stacked, composite codes and
- dot codes; Digital Watermarks on specific models
- Choice of Bluetooth wireless technology version or Datalogic’s STAR
- Cordless System (radio frequencies available in 433 MHz or 910 MHz)
- Wireless battery charging system
- Choice of WLC4090 adjustable position cradle with Scan-While-Charging capability or
- WLC4190 sleek desk/wall cradle with USB Type C connectivity
- Disinfectant-Ready enclosures withstand daily cleaning with harsh disinfectant solutions
- Specific black models with enclosures treated with anti-microbial additives available
- (ISO22196 compliant)
- EASEOFCARE Service Plans offer a wide range of service options to protect
- your investment, ensuring maximum productivity and ROI
Datalogic Gryphon I GBT4500, Imager, 2D, BT, Digimarc
3.350,00kr. Excl. VAT
Gryphon GBT4500, 2D MP Imager, Digimarc, Wireless Charging, Black-
- Description
- Additional information
- Documents
Description
Datalogic Gryphon GBT4500. Type: Handheld bar code reader, Scanner type: 1D/2D, Sensor type: Laser. Connectivity technology: Wireless, Standard interfaces: Bluetooth, Wireless range: 100 m. Product colour: Black, International Protection (IP) code: IP52. Power source type: Battery, Battery technology: Lithium Polymer (LiPo), Battery capacity: 3250 mAh. Weight: 235 g, Width: 109 mm, Depth: 68 mm
IMAGING TECHNOLOGY
The Gryphon 4500 series represents the premium range of handheld scanners from Datalogic for value added applications. Designed with people in mind, the Gryphon 4500 series stands out with its elegant and cutting edge design, the unchallenged ergonomics, and features the most advanced Megapixel sensor with white-illumination 2D technology for outstanding performance.
SIMPLE TO USE AND DEPLOY
The Gryphon I 4500 omnidirectional imager provides snappy reading performance on all common 1D and 2D codes as well as postal, stacked, and composite codes like PDF417. High Density (HD) models are also available for reading smaller, condensed codes. A dedicated version with red illumination optics reads Digital Watermarking. For mobile marketing or ticketing applications, this imager also offers excellent performance when reading bar codes from mobile devices. The
enhanced optics offer improved motion tolerance and first pass decoding of fast moving codes.
READY TO BE REGULARLY CLEANED AND DISINFECTED
Most working environments now have requirements that scanners need to be regularly cleaned and disinfected. The Gryphon 4500 series utilizes Disinfectant-Ready enclosures, designed to withstand regular daily cleaning with harsh disinfectant solutions commonly used in a healthcare environment.
WIRELESS COMMUNICATIONS AND WIRELESS CHARGING
Featuring Bluetooth® wireless technology (GBT models) or narrow band radio communications with Datalogic’s STAR Cordless System™ (GM models), the Gryphon 4500 wireless readers provide maximum flexibility to solve any end user application with the best technical solution. One of the most important technical innovations that the Gryphon 4500 wireless scanners achieve is the battery recharge through an inductive charging system, lowering the total cost of ownership because it
eliminates the need for contacts’ cleaning and maintenance procedures. The maximum reliability offered by the wireless charging technology means 24/7 activities with no stops for maintenance or repair and toplevel operating productivity and performance.
Additional information
Type | Handheld bar code reader |
---|---|
Scanengine | |
Scanner type | 1D/2D |
Sensor type | Laser |
Connection | |
Optical sensor resolution (W x H) | 1280 x 800 pixels |
Light levels (direct sunlight) | 0 – 100000 lx |
Tilt reading angle | 0 – 360° |
Pitch reading angle | -65 – 65° |
Yaw reading angle | -65 – 65° |
Connectivity technology | Wireless |
Standard interfaces | Bluetooth |
Wireless range | 100 m |
Bluetooth version | 4.0 |
Product colour | Black |
Power source type | Battery |
Input voltage | 4.5 – 14 V |
Weight | 235 g |
Width | 109 mm |
Depth | 68 mm |
Height | 166 mm |
Operating temperature (T-T) | 0 – 50 °C |
Storage temperature (T-T) | -40 – 70 °C |
Operating relative humidity (H-H) | 5 – 95% |
Harmonized System (HS) code | 84716070 |
2D (matrix & stacked) barcodes supported | Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, MaxiCode, Micro QR Code, MicroPDF417, QR Code |
Wavelength | 650 nm |
International Protection (IP) code | IP52 |
Operating frequency | 2400 MHz |
Battery technology | Lithium Polymer (LiPo) |
Battery capacity | 3250 mAh |
Number of reads per charge | 80000 |
Charging time | 4 h |
Linear (1D) barcodes supported | GS1 DataBar, GS1 DataBar Expanded, PDF417 |
Battery voltage | 12 V |
Compliance certificates | RoHS |
