TSC DA320, 12 dots/mm (300 dpi), RTC, EPL, ZPL, ZPLII, TSPL-EZ, USB, RS232, Ethernet
HIGHLIGHTS
- Small Parcel Shipping
- Mail Room Address and Routing Labels
- Shipping & Receiving
- Entertainment and Transportation Ticketing
- Retail Point-of-Sale
- File-Folder Labeling
- Description
- Additional information
Description
TSC DA320. Print technology: Direct thermal, Maximum resolution: 300 x 300 DPI, Print speed: 102 mm/sec. Connectivity technology: Wired, Ethernet LAN, USB port. Product colour: Black
The DA Series of direct thermal desktop printers is ideal for a wide variety of applications including product marking, point of sale, retail, small office, shipping labels, and other labeling and tag applications at a very competitive price.
The DA Series is a perfect combination of affordability with a durable and reliable design. The DA series offers both 203 and 300 dpi print resolution with printing speeds up to a fast 6 ips. The large 60-watt power supply produces high quality printed labels, even at its fastest print speeds.
4 Models Available
The DA Series consists of four models, the DA210, DA220, DA310, and DA320, designed to provide the right fit for your application. All four models handle up to 5-inch OD rolls of direct thermal labels and can print crisp, clear barcodes, graphics and text at up to 6-inches per second.
Affordable
The low cost DA210 and DA310 models are priced right and have the features you need for most basic label printing needs using a USB 2.0 or optional Bluetooth interface.
Wireless and Hardwire Communications
Need more communications power? The DA220 and DA320 models have more memory and support nearly every major communications option including Serial RS-232, Ethernet, USB host, internal 802.11 a/b/g/n wireless, or internal Bluetooth.
Emulations and More
The DA220 and DA230 models have plenty of memory with 128 MB Flash & 64 MB SDRAM that can be used for easy storage of fonts, international character sets, and graphics. Right out of the box, it supports a fully compatible set of standard industry emulations, including Line Mode, Eltron®, Zebra® and Datamax languages, making it easy to replace old installed hardware.
Scan & Camera
| Built-in barcodes | 1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, Interleaved 2/5, MaxiCode, MicroPDF417, PDF417, QR Code, UPC-A, UPC-E |
| Print technology | Direct thermal |
| Print speed | 102 mm/sec |
| Maximum printing width | 10.6 cm |
| Page description languages | DPL, EPL, ZPL, ZPL II |
| Number of fonts | 8 |
| Printable dot numbers | 12 dot |
| Printing colours | Black |
Media & Labels
| Maximum label width | 11.4 cm |
| Media thickness | 0.055 - 0.19 mm |
| Maximum media length | 11.4 m |
Display
| Maximum resolution | 300 x 300 DPI |
| Display | No |
| Built-in display | No |
Connectivity & Ports
| Connectivity technology | Wired |
| Ethernet LAN | Yes |
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
| RS-232 ports | 1 |
Wireless & Network
| Wi-Fi | No |
Processor & Memory
| Internal memory | 64 MB |
| Flash memory | 128 MB |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Built-in processor | Yes |
Dimensions, Weight & Design
| Product colour | Black |
| Width | 172 mm |
| Depth | 195 mm |
| Height | 165 mm |
| Weight | 1.5 kg |
| Colour | No |
Operating Conditions
| Operating relative humidity (H-H) | 25 - 85% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 5 - 40 °C |
| Storage temperature (T-T) | -40 - 60 °C |
Certifications
| Certification | FCC Class A, CE Class A, RCM, CB, CCC, ENERGY STAR, KC, BIS, UL, EAC, RoHS, WEEE |
