Epson TM-P20II, 8 dots/mm (203 dpi), USB-C, BT, kit (USB), white
HIGHLIGHTS
- All-new, compact and stylish design: Features an ergonomic and light form-factor that's intuitive to use.
- Print anywhere, anytime: Perfect for on-the-go environments, including in-vehicle applications.
- Extremely robust and reliable: Improved impact resistance, and IP54-rated for dust and water ingress.
- Excellent connectivity: USB-C and W-Fi, plus a W-Fi Direct mode for effortless printing.
- Easy to set-up and configure: Supplies with "Quick-start" sheet with QR-code links to video guides.
- Description
- Additional information
- Documents
Description
Epson TM-P20II (106): Mobile Receipt, Bluetooth, USB-C, White EMEA. Print technology: Thermal, Maximum resolution: 203 x 203 DPI, Print speed: 100 mm/sec. Supported paper width: 58 mm, Maximum printing width: 5.8 cm. Interface: Bluetooth, USB Type-C. Built-in barcodes: Code 128 (A/B/C), CODABAR (NW-7), UPC-E, UPC-A, GS1 DataBar, EAN8, GS1-128, EAN13, Code 39, Data…, Sound pressure level (printing): 53 dB, Mean time between failures (MTBF): 120000 h. Product colour: White
Exceptional performance
Sporting an all-new, ultra-light and stylish design, Epson’s TM-P20II portable receipt printer offers a range of new and advanced features, as well as enhanced durability. Providing outstanding flexibility, reliability, connectivity and ease-of-use, it’s perfect for busy, on-the-go environments such as retail, hospitality and in-vehicle applications.
Delivering exceptional performance in a compact, stylish and ultra-light design, the all-new TM-P20II is ideal for anyone who needs receipt printing on-the-go. Now also approved for in-vehicle applications, it’s even more robust than ever, providing increased impact resistance and protection to IP54 standards, and can be easily mounted onto a belt, or shoulder carried. With USB-C connectivity, plus support for Bluetooth 5.0 “classic” and low-energy modes, it provides excellent range, seamless pairing and reliable all-day battery life, while its Wi-Fi 5 capability means that it offers excellent wireless performance, including a Wi-Fi “Direct” mode, enabling direct connection of up to 8 devices without the need to connect to a network or hotspot. Supplied with a comprehensive “quick start” sheet, which includes QR-codes that link to video guides, set-up and configuration is fast and easy.
12 months Carry in
Scan & Camera
| Built-in barcodes | Code 128 (A/B/C), CODABAR (NW-7), UPC-E, UPC-A, GS1 DataBar, EAN8, GS1-128, EAN13, Code 39, Data Matrix, Code 93, ITF, MaxiCode, PDF417 |
| Print technology | Thermal |
| Maximum printing width | 5.8 cm |
| Sound pressure level (printing) | 53 dB |
| Print speed (receipt) | 100 mm/sec |
| Printing characters | Graphic, Barcode, 2D barcode, Text |
| Print head life | 50 km |
| Font styles | ANK, BIG5, GB18030-80, JIS X0208-90, KSC-5601C, Traditional Chinese, Simplified Chinese |
| Print speed | Max. 100 mm/sec at 203 x 203 DPI ( printing width58 mm) |
Media & Labels
| Supported paper width | 58 mm |
| Paper size roll paper | 57.50 ± 0.50 (W) mm x dia 40.00 mm |
Display
| Maximum resolution | 203 x 203 DPI |
Connectivity & Ports
| Interface | Bluetooth, USB Type-C |
Wireless & Network
| Near Field Communication (NFC) | Yes |
Battery & Power
| Battery life (max) | 27 h |
Dimensions, Weight & Design
| Product colour | White |
| Width | 79 mm |
| Depth | 120 mm |
| Height | 46 mm |
| Weight | 220 g |
| Package weight | 596 g |
| Quantity per pack | 1 pc(s) |
| Package width | 220 mm |
| Package depth | 162 mm |
| Package height | 95 mm |
| Buffer size | 64 KB |
Operating Conditions
| Operating temperature (T-T) | -15 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Mean time between failures (MTBF) | 120000 h |
In the box
| Box contents | Battery (OT-BY20), Belt clip, Main unit, Quick Start Guide, Roll paper, Setup guide, USB cable, Warranty document |
Other specifications
| Country of origin | Philippines |
| Paper save function | Yes |
| Technology | Thermal Line |
