Epson TM-T88VII, USB, USB Host, RS232, Ethernet, ePOS
HIGHLIGHTS
- Reliable hardware Backed by our tried and trusted build quality
- High performance Max print speed 500mm/s
- Connectivity and interface options USB, Ethernet, USB Host as standard; serial, PoweredUSB, options
- Backwards compatible Fully compatible with the existing T88V and T88VI software
- Reduced environmental impacts Low power consumption, support for Phenol-free paper
- Description
- Additional information
- Documents
Description
Epson TM-T88VII (112A0). Print technology: Thermal, Type: POS printer, Maximum resolution: 180 x 180 DPI. Printing media thickness: 48 – 80 µm, Maximum roll diameter: 8.3 cm, Supported paper width: 80 mm. Connectivity technology: Wired & Wireless, USB connector: USB Type-A / USB Type-B, Serial interface type: RS-232. Sound pressure level (printing): 52 dB, Sound pressure level (standby): 52 dB, Mean time between failures (MTBF): 360000 h. Product colour: Black
High-speed receipt printer
Market-leading1, high-performance and eco-conscious receipt printers, backed by proven reliability
The TM-T88VII is our new high-performance receipt printer range. It features a range of design, connectivity and usability improvements and enhancements to improve the user experience.
Reliable and high-performance
Avoid downtime by choosing proven, reliable hardware from the market leader1. Fast print speeds of 500mm/s and high-quality, printed legible receipts will ensure happy customers.
Backwards compatible
The TM-T88VII is fully compatible with the existing T88V and T88VI software so there are no expensive costs associated with changing business infrastructure. The printer also has same footprint as previous models, meaning no additional costs of having to change the counters/tills.
Eco-conscious
The TM-T88VII demonstrates reduced environmental impacts, with lower noise level, lower power consumption and smaller, more efficient power supply. The printer is now compatible with more eco-friendly, Phenol-free paper.
Reliable hardware Backed by our tried and trusted build quality
High performance Max print speed 500mm/s
Connectivity and interface options USB, Ethernet, USB Host as standard; serial, PoweredUSB, options
Backwards compatible Fully compatible with the existing T88V and T88VI software
Reduced environmental impacts Low power consumption, support for Phenol-free paper
| Print technology | Thermal |
| Print speed | 500 mm/sec |
| Printing media thickness | 48 - 80 µm |
| Sound pressure level (printing) | 52 dB |
| Autocutter durability | 3 million cuts |
| Power consumption (printing) | 27.9 W |
| Printing characters | Text, Graphic, Barcode, 2D barcode |
| Character sets | ANK |
| Print head life | 200 km |
| Column capacity | 42/56 |
| Character size | 1.41 x 3.39 mm |
Media & Labels
| Supported paper width | 80 mm |
| Maximum roll diameter | 8.3 cm |
| Media thickness | 48 - 80 mm |
Display
| Maximum resolution | 180 x 180 DPI |
Connectivity & Ports
| Connectivity technology | Wired & Wireless |
| USB port | Yes |
| Ethernet LAN | Yes |
| Serial interface | Yes |
| Serial interface type | RS-232 |
| USB connector | USB Type-A / USB Type-B |
| Changeable interface | Y |
Wireless & Network
| Wall mountable | Yes |
| Near Field Communication (NFC) | Yes |
Audio
| Sound pressure level (standby) | 52 dB |
Processor & Memory
| AC input voltage | 24 V |
Software & OS
| Pre-installed software | Server Direct Print, ePOS-Device, ePOS-Display, ePOS-Print |
Battery & Power
| Power consumption | 27900 mA |
| Power consumption (standby) | 1.4 W |
Dimensions, Weight & Design
| Product colour | Black |
| Width | 145 mm |
| Depth | 195 mm |
| Height | 148 mm |
| Weight | 1.7 kg |
| Package weight | 2.7 kg |
| Quantity per pack | 1 pc(s) |
| Package width | 195 mm |
| Package depth | 235 mm |
| Package height | 260 mm |
| Products per pallet | 112 pc(s) |
| Products per pallet (UK) | 168 pc(s) |
| Mounting position | Horizontal/Vertical |
| Buffer size | 4 KB |
| Pallet weight (UK) | 0 g |
| Pallet gross weight | 0 g |
Operating Conditions
| Operating temperature (T-T) | 5 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| Mean time between failures (MTBF) | 360000 h |
| Mean cycles between failures (MCBF) | 70000000 |
Certifications
| Harmonized System (HS) code | 84433210 |
| Certification | CE |
Other specifications
| Type | POS printer |
| Country of origin | Philippines |
| Optional connectivity | Wireless LAN |
| Paper save function | Yes |
| Built-in sensors details | Paper End Sensor, Paper Near End Sensor, Cover Open Sensor, Receipt paper sensor |
| Lifetime | 20000000 lines |
