Elo I-Series 2.0, 54,6cm (21,5”), Projected Capacitive, SSD, 10 IoT Enterprise, black
HIGHLIGHTS
- All-in-One tablet PC Black 100 W
- Intel® Celeron® J4105 1.5 GHz Processor cores: 4
- Touchscreen 54.6 cm (21.5") Full HD 1920 x 1080
- 4 GB DDR4-SDRAM 2666 MHz 1 x 4 GB
- 128 GB SSD
- Intel® UHD Graphics 600
- Wi-Fi 5 (802.11ac) Ethernet LAN 10,100,1000 Mbit/s Bluetooth 5.0
- Windows 10
Elo I-Series 2.0, 54,6cm (21,5”), Projected Capacitive, SSD, 10 IoT Enterprise, black
PCAP i2, 21.5” diagonal, Active matrix TFT LCD (LED) 1920 x 1080, Intel Celeron J4105 Processor, Intel UHD Graphics 600, 4GB 2666MHz DDR4 SO-DIMM, 128GB M.2 SATA SSD, Windows 10 IoT Enterprise LTSC 64-bit
1.133,00 € Excl. VAT
- Description
- Additional information
- Documents
Description
Elo Touch Solutions I-Series E692640. Product type: All-in-One tablet PC. Display diagonal: 54.6 cm (21.5″), HD type: Full HD, Display resolution: 1920 x 1080 pixels, Touchscreen, Screen shape: Flat. Processor family: Intel® Celeron®, Processor frequency: 1.5 GHz. Internal memory: 4 GB, Internal memory type: DDR4-SDRAM. Total storage capacity: 128 GB, Storage media: SSD. On-board graphics card model: Intel® UHD Graphics 600. Operating system installed: Windows 10. Product colour: Black
I-Series for Windows
Elo’s I-Series for Windows delivers commercial-grade computing with the capabilities, security and enterprise infrastructure of a powerful, Windows-based platform—all in a sleek, yet durable fixed tablet form factor.
Built on a modular platform and available with either 15-inch or 22-inch displays, the I-Series for Windows can be found in installations across the globe, from in-store interaction and point-of-sale to self-service, hospitality and corporate office environments. The uses are virtually unlimited.
Endless Versatility
The Elo I-Series offers versatility across environments. From retail and entertainment to corporate offices and signage, the I-Series is an excellent choice to meet the demands of continuous public use.
Configure with Elo Edge Connect
Built with versatility in mind, the Elo Edge Connect system offers a wide assortment of peripherals that seamlessly attach to the edge of the touchscreen. And you can add or swap them out later as your needs change.
Stands & Mounts
With a standard VESA mount, we give you the flexibility to mount our products however you want.
Windows or Linux. You Choose.
Elo’s I-Series utilizes the reliability-tested performance and security of Intel’s 8th-generation processors and vPro™ platform. Available with Windows 10 or, for added flexibility, the I-Series offers models with no OS-all pretested with Linux SuSE, Ubuntu and Red Hat operating systems-allowing businesses to get the solution best suited for them.
Get Peace of Mind With EloCare
EloCare is service and support from the people who know your Elo products best. From extended warranties and on-site exchange to advance unit replacement and field services, the highly skilled Elo technical specialists will get you up and running.
Scan & Camera
| Built-in camera | No |
Media & Labels
| Storage media | SSD |
| Processor ARK ID | 128989 |
Display
| Display diagonal | 54.6 cm (21.5″) |
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | Yes |
| HD type | Full HD |
| LED backlight | Yes |
| Touch technology | Multi-touch |
| Native aspect ratio | 16:9 |
| Display brightness | 225 cd/m² |
| Screen shape | Flat |
| Number of displays supported (on-board graphics) | 3 |
| VESA mounting | Yes |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| Detachable display | No |
| Display number of colours | 16.78 million colours |
Connectivity & Ports
| Maximum internal memory supported by processor | 8 GB |
| Memory types supported by processor | DDR4-SDRAM, LPDDR4-SDRAM |
| Memory clock speeds supported by processor | 2400 MHz |
| Memory channels supported by processor | Dual |
| ECC supported by processor | No |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Wireless & Network
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Bluetooth | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Bluetooth version | 5.0 |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Execute Disable Bit | Yes |
| Embedded options available | No |
| Compatible memory cards | Not supported |
Audio
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 2 W |
Processor & Memory
| Processor family | Intel® Celeron® |
| Processor manufacturer | Intel |
| Processor model | J4105 |
| Processor frequency | 1.5 GHz |
| Processor boost frequency | 2.5 GHz |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor cache | 4 MB |
| Thermal Design Power (TDP) | 10 W |
| PCI Express slots version | 2.0 |
| Processor socket | BGA 1090 |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor codename | Gemini Lake |
| Maximum number of PCI Express lanes | 6 |
| PCI Express configurations | 1x2, 1x2+2x1, 1x4, 2x1, 4x1 |
| Conflict-Free processor | Yes |
| Internal memory | 4 GB |
| Maximum internal memory | 8 GB |
| Internal memory type | DDR4-SDRAM |
| Memory slots | 2 |
| Memory slots type | SO-DIMM |
| Memory clock speed | 2666 MHz |
| Memory layout (slots x size) | 1 x 4 GB |
| Total storage capacity | 128 GB |
| Optical drive type | No |
| Total SSDs capacity | 128 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 128 GB |
| SSD form factor | M.2 |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card | Yes |
| On-board graphics card model | Intel® UHD Graphics 600 |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card base frequency | 250 MHz |
| On-board graphics card burst frequency | 750 MHz |
| On-board graphics card dynamic frequency (max) | 750 MHz |
| Maximum on-board graphics card memory | 8 GB |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.4 |
| On-board graphics card ID | 0x3185 |
| Trusted Platform Module (TPM) | Yes |
| Intel® Smart Response Technology | No |
| Intel® Turbo Boost Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Enhanced Halt State | Yes |
| Intel® Secure Key | Yes |
| Intel® OS Guard | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Idle States | Yes |
| Processor package size | 25 x 24 mm |
| CPU configuration (max) | 1 |
| Intel Identity Protection Technology version | 1.00 |
| Intel Smart Response Technology version | 0.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| AC adapter input voltage | 100 - 240 V |
Software & OS
| Operating system installed | Windows 10 |
Battery & Power
| AC adapter power | 100 W |
| AC adapter frequency | 50-60 Hz |
| AC adapter included | Yes |
Dimensions, Weight & Design
| Product colour | Black |
| Width (with stand) | 525.9 mm |
| Depth (with stand) | 52.6 mm |
| Height (with stand) | 319.2 mm |
| Weight (with stand) | 5.2 kg |
| Package width | 625 mm |
| Package depth | 196 mm |
| Package height | 437 mm |
| Package weight | 7 kg |
Operating Conditions
| Operating temperature (T-T) | 0 - 35 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 5 - 95% |
Certifications
| Product type | All-in-One tablet PC |
| Harmonized System (HS) code | 84713000 |
In the box
| Pen included | No |
| Quick start guide | Yes |
Other specifications
| Response time | 14 ms |
| 64-bit computing | Yes |
| Tjunction | 105 °C |
| Card reader integrated | No |
| Number of execution units | 12 |
| Thermal Monitoring Technologies | Yes |
| 3D | No |
