Honeywell presentation scanner, 1D/2D, Black,

HIGHLIGHTS

  • Handheld bar code reader Black
  • Scanner type: 1D/2D Sensor type: Laser
  • Code 39, GS1 DataBar Omnidirectional, U.P.C. Data Matrix, PDF417, QR Code
  • Working distance: 32.7 cm
  • Wired Standard interfaces: Keyboard wedge, RS-232, RS-485, USB

Honeywell presentation scanner, 1D/2D, Black,

laser, omnidirectional, imager, 1120 scans/sec
incl.: cable (USB, straight, 3 m), desk-/wall hold

Orbit 7190g, USB-kit, 1D/2D

2.049,00kr. Excl. VAT

SKU: 7190G-2USBX-0 Delfi nr.: 7400434
In stock – 2-5 days delivery

Description

Honeywell Orbit 7190g. Type: Handheld bar code reader, Scanner type: 1D/2D, Sensor type: Laser. Connectivity technology: Wired, Standard interfaces: Keyboard wedge, RS-232, RS-485, USB. Product colour: Black, LED indicators: Status, Certification: CE, RoHS. Input voltage: 5 V, Power consumption: 472 mA. Weight: 410 g, Width: 108 mm, Depth: 103 mm

The Orbit™ 7190g scanner incorporates breakthrough hybrid technology that combines omnidirectional laser scanning and integrated area-imaging to provide a barcode reading platform optimized for highly efficient checkouts. Like other Orbit scanners, it delivers superior pass-through scanning of merchandise linear barcodes, while simultaneously helping retailers address the growing need for digital barcodes reading – without requiring an additional scanner.

Like other Orbit scanners – the best-selling hands-free scanners of all time – the Orbit 7190g scanner is an innovative, elegant and affordable solution for convenience retail applications where counter space is at a premium. The award-winning shape enables handheld scanning of large, bulky items. For added flexibility, the scanning head can be tilted within a 30° range to accommodate objects of various sizes and shapes.

The Orbit 7190g scanner seamlessly works for both merchandise scanning by the cashier, and digital barcodes scanning off smartphones by customers. With the dual-modes design, the scanner is automatically optimized for both applications while eliminating the customer annoyance of a laser and LED illumination.

The Orbit 7190g is a plug-and-play scanner, and installing it into existing checkout systems is easy. Multiple on-board interfaces make the Orbit 7190g scanner compatible with most POS systems, and automatic interface detection enables the scanner to configure itself to the appropriate interface upon connection – eliminating the cumbersome task of scanning programming barcodes. The Orbit 7190g scanner also simplifies integration by drawing power directly through USB, eliminating the need for an additional power supply and cabling.

FEATURES & BENEFITS
– The Orbit 7190g scanner integrates both a laser and an imager into a single presentation scanner – no need to buy a separate scanner for digital barcode reading, while maintaining superior merchandise barcode scanning.
– With dual-working modes, the scanner is optimized for both scanning digital codes off customer smartphones and scanning merchandise codes by the cashier at the register.
– A 20-line omnidirectional laser pattern maintains the proven 1D scanning performance of existing Orbit scanners. With leading Honeywell imaging technology, the scanner reads smartphone coupons and ID cards with ease.
– The award-winning shape enables handheld scanning of large, bulky items. The adjustable scan head even allows cashiers to tilt the scanner 30° for targeted scanning of larger products.
– Automatic interface detection enables the scanner to configure itself to the appropriate interface upon connection –  eliminating the tedious task of scanning programming barcodes.

3-year

Scan & Camera

Scanner type1D/2D
Scanengine1D, 2D
Pitch reading angle0 - 60°
Yaw reading angle0 - 70°
2D (matrix & stacked) barcodes supportedData Matrix, PDF417, QR Code
Linear (1D) barcodes supportedCode 39, GS1 DataBar Omnidirectional, U.P.C.
Read rate (max)1120 reads/s
Working distance32.7 cm

Display

Built-in displayNo

Connectivity & Ports

ConnectionCabled
Standard interfacesKeyboard wedge, RS-232, RS-485, USB
Cables includedUSB

Processor & Memory

Input voltage5 V

Battery & Power

Power consumption472 mA

Dimensions, Weight & Design

Product colourBlack
Weight410 g
Width108 mm
Depth103 mm
Height148 mm

Operating Conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)5 - 95%

Certifications

Harmonized System (HS) code84716070
CertificationCE, RoHS
Compliance certificatesRoHS

Other specifications

TypeHandheld bar code reader
Sensor typeLaser
Light levels (direct sunlight)4842 - 100000 lx
Connectivity technologyWired
LED indicatorsStatus
