Elo I-Series 5.0 Slate, 39.6 cm (15,6”), Projected Capacitive, 10 TP, Full HD, USB, USB-C, BT, Ethernet, Wi-Fi, QCS6490, Android, GMS, black

HIGHLIGHTS

  • Indoor Digital signage flat panel Grey
  • 39.6 cm (15.6") 1920 x 1080 pixels LED 350 cd/m²
  • Touchscreen 60 Hz 20 ms
  • Ethernet LAN Wi-Fi
  • Built-in speaker(s) 2 W

Elo I-Series 5.0 Slate, 39.6 cm (15,6”), Projected Capacitive, 10 TP, Full HD, USB, USB-C, BT, Ethernet, Wi-Fi, QCS6490, Android, GMS, black

15.6”, 1920 x 1080 @ 60Hz, Qualcomm Snapdragon QCS6490, 8 GB, 16:9, 100 – 240 V AC, 50 – 60 Hz, 370.3 x 221.3 x 15.1 mm, 1.56 kg, dark gray metallic

9.582,00kr. Excl. VAT

SKU: E540697
In stock – 2-5 days delivery

Description

Elo Touch Solutions I-Series 5 Slate. Product design: Digital signage flat panel. Display diagonal: 39.6 cm (15.6″), Display technology: LED, Display resolution: 1920 x 1080 pixels, Display brightness: 350 cd/m², HD type: Full HD, Touchscreen. Wi-Fi. Operating system installed: Android. Product colour: Grey

15-inch I-Series 5 Slate
Touchcomputer

Elo’s I-Series 5 Slate delivers a powerful 15.6-inch Full HD interactive system, complete with Android 14 OS, Qualcomm processor and an I/O hub. Built to be one of the thinnest commercial-grade fixed tablet form factors, the I-Series 5 Slate delivers a stunning design, enhanced durability, increased touch accuracy and brilliant display clarity.

Interactive signage has never looked so good.

Create your POS system.
Transform the I-Series 5 Slate it into a powerful, industrial-design POS system that scales with your business.

Connectivity for all your accessories.
The I‑Series 5 Slate offers an I/O hub that extends connectivity from the display to your accessories.

Get enterprise support with Elo EssentialEdge.
With easy-to-use development kits, robust management tools, world class life cycle management and security, Elo can help you deliver the convenience and familiarity of Android interfaces in a secure, business-friendly way.

OS 360 – Take advantage of monthly security updates to keep your devices secure.

Seamless Provisioning – Leverage EloView or Google Zero Touch to easily set up your device.

Elo OEMConfig – Get Elo’s proprietary APIs on your preferred Android MDM platform, saving months of effort as new releases become available.

Commercial-grade performance.
The Backpack is backed by the powerful Qualcomm 6490 octa-core processor to deliver the performance businesses need.

Expand possibilities with Applied AI.
The Qualcomm 6490 chipset offers a fused AI accelerator, enabling astonishing performance at low power. These features and more produce a combined AI performance of up to 12 TOPS.

Manage your devices easily with EloView.
EloView allows you to deploy and securely manage your entire network of Android-powered Elo devices from anywhere in the world.
– Remotely deploy content and manage your devices securely.
– Provision your devices in seconds with a seamless out-of-the-box experience.
– Leverage Elo Home to create a customized interface on your Elo device.

Google Mobile Services Ready.
With Google Mobile Services and EloView, managing Android devices and your apps is simplified. You can remotely deploy and manage your device, adjust detailed settings, and take advantage of the latest Google-powered features. Not only does this make management easier, but it also ensures your Elo devices meet the high standards required for Google CTS verification, giving you peace of mind.

Scan & Camera

Built-in cameraYes
Megapixel (approx.)8 MP

Display

Display diagonal39.6 cm (15.6″)
Display technologyLED
Display resolution1920 x 1080 pixels
Display brightness350 cd/m²
TouchscreenYes
Touchscreen technologyProjected capacitive system
Contrast ratio (typical)1000:1
Viewing angle, horizontal170°
Viewing angle, vertical170°
Display number of colours16.7 million colours
VESA mountingYes
Screen shapeFlat
Panel mounting interface75 x 75 mm
Aspect ratio16:9
HD typeFull HD
Panel typeTFT-LCD
Display diagonal (metric)396.24 cm
DisplayPorts quantity1
Native refresh rate60 Hz
Active display area (W x H)344 x 194 mm
Display width370.3 mm
Display depth15.1 mm
Display height221.3 mm
Display weight1.56 kg
Number of displays1
DisplayPorts out1

Connectivity & Ports

Cables includedPower
Ethernet LAN (RJ-45) ports1
Placement supportedIndoor
USB portYes
USB ports quantity4
Ethernet LANYes
USB connector typeUSB Type-A, USB Type-C
Ethernet LAN data rates1000 Mbit/s

Wireless & Network

Wi-FiYes
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)

Audio

Built-in speaker(s)Yes
RMS rated power2 W
Number of built-in speakers2
Number of microphones2

Processor & Memory

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Built-in processorYes
Processor manufacturerQualcomm
Processor cores8
Internal memory8 GB
Internal storage capacity64 GB

Software & OS

Operating system installedAndroid
Operating system versionAndroid 14

Battery & Power

Power consumption (typical)8.5 W
Power consumption (off)0.4 W
Power consumption (sleep)3 W

Dimensions, Weight & Design

Product colourGrey
Package width445 mm
Package depth160 mm
Package height308 mm
Package weight3.51 kg
Product designDigital signage flat panel

Operating Conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)20 - 80%
Storage temperature (T-T)-20 - 50 °C
Storage relative humidity (H-H)10 - 90%
Mean time between failures (MTBF)50000 h

Certifications

CertificationUL/cUL (US)FCC (US)IC (Canada)CE (Europe)CB (International)VCCI, MIC (Japan)RCM (Australia)
PurposeCommercial

Other specifications

Response time20 ms
Number of simultaneous touchpoints10
Multi-touchYes
OrientationHorizontal/Vertical
