Zebra ZT230 Label Printer, TT, 203dpi, USB/RS232,


HIGHLIGHTS
- Thermal transfer
- 203 x 203 DPI
- Maximum printing width: 10.4 cm Print speed: 152 mm/sec
- Built-in barcodes: 1D, 2D, Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, MaxiCode, PDF417, POSTNET, TLC39, UPC-A, UPC-E
- Connectivity technology: Wired
- USB port
- Display: LCD
- 9.1 kg
Zebra ZT230 Label Printer, TT, 203dpi, USB/RS232,
6.545,00kr. Excl. VAT
ZT230 Industrial Printer, TT, ZPL, 203Dpi, RS232, USB, 128MB Flash
Stock visibility Not in stock
- Description
- Additional information
Description
Zebra ZT230. Print technology: Thermal transfer, Maximum resolution: 203 x 203 DPI, Print speed: 152 mm/sec. Connectivity technology: Wired. Product colour: Black, White
ZT230 Industrial Printer
The durability of a metal frame and cover with an icon based LCD graphical user interface and larger ribbon capacity for long lasting use in demanding environments.
Zebra incorporated extensive customer feedback, as well as the legacy of our industry leading Stripe and S4M printers, to create the new ZT200 Series family of printers with elegant space-saving design, effortless setup, intuitive user operation, and ease of service and maintenance.
SIMPLIFIED OPERATION AND OUTSTANDING VALUE
The ZT200 series is designed to simplify and shorten servicing and consumable replacement time. The easy tool-less platen and print head removal makes it easy for operators to maintain the printer. The side loading supplies path enables simplified media and ribbon insertion and color coded media path clearly directs media and ribbon threading.
COMPACT FOOTPRINT FITS WHERE SPACE IS AT A PREMIUM
The ZT200 Series printerโs compact design, when closed and opened, fits easily in constrained work areas. The ergonomic Bi-fold door requires only 4โ (102mm) of door swing room. This reduces the printer height making it ideal for placement under a shelf or against another item.
Additional information
Print technology | |
---|---|
Maximum resolution | 203 x 203 DPI |
Print type | |
Print speed | 152 mm/sec |
Print width | |
Maximum printing width | 10.4 cm |
Resolution | |
Maximum label width | 11.4 cm |
Maximum label length | 0.991 m |
Media thickness | 0.076 – 0.025 mm |
Connectivity technology | |
Ethernet LAN | No |
Wi-Fi | No |
USB port | Yes |
Internal memory | 128 MB |
Flash memory | 128 MB |
Product colour | Black, White |
Display | LCD |
Operating relative humidity (H-H) | 20 – 85% |
Storage relative humidity (H-H) | 5 – 85% |
Width | 242 mm |
Depth | 432 mm |
Height | 277 mm |
Weight | 9.1 kg |
Harmonized System (HS) code | 84433210 |
USB 2.0 ports quantity | 1 |
RS-232 ports | 1 |
Certification | IEC 60950, EN 55022 B, EN 55024, EN 61000-3-2, EN 61000-3-3, cTUVus, CE, FCC-B, ICES-003, VCCI, C-Tick, NOM, S Mark, CCC, GOST-R, KCC, BSMI |
Ribbon length | 450 m |
Built-in barcodes | 1D, 2D, Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, MaxiCode, PDF417, POSTNET, TLC39, UPC-A, UPC-E |
Ribbon width | 11 cm |
Maximum media length | 3.99 m |
Sustainability certificates | ENERGY STAR |
Optional connectivity | Ethernet, Parallel, Wireless LAN |
Media thickness (imperial) | 0.003 – 0.01" |
Maximum media length (imperial) | 157" |
Power requirements | 100 – 240 VAC, 47 – 63 Hz |
Storage temperature (T-T) | -40 – 140 ยฐF |
Housing material | Metal |
Operating temperature (T-T) | 32 – 105 ยฐF |
Built-in display | Yes |
